Faber CYLINDRA ISOLA EG10 X A37 [12/22] Activated charcoal filter recirculation version

Activated Charcoal Filter (Recirculation Version)

This cannot be washed or regenerated, and must be changed when led S1 starts to flash, or at

least once every 4 months. The Alarm signal, if it has been activated, only appears when the

Suction motor is turned on.

Activating the alarm signal

• In Recirculation Version Hoods, the Filter Saturation Alarm must be activated on installa-

tion or at a later date.

• Turn the Lights and the Suction Motor off.

• Press button T2 and hold it for 5 seconds until the LED flashes twice in confirmation:

CHANGING

Resetting the alarm signal

• Turn the Lights and the Suction Motor off.

• Press T3 and hold for at least 3 seconds, until LED flashes

three times in confirmation.

Changing the Filter

• Open the lighting unit by pulling on the notch provided.

• Remove the Metal Grease Filter

• Remove the saturated Activated charcoal filter, using the hooks

provided.

• Fit the new Filter, hooking it into place.

• Fit the Grease filter and the Light Unit back into place.

Lighting

LIGHT REPLACEMENT

20 W halogen light.

• Extract the lamp from the lamp holder by pulling gently.

• Replace with another of the same type, making sure that the

two pins are properly inserted in the lamp holder socket holes.
