- 14 -

ENGLISH

GENERAL

Carefully read the contents of this leaflet since it pro-

vides important instructions regarding safety of installa-

tion, use and maintenance.

Keep the leaflet for possible future consultation. All the

operations relating to installation/replacement (electrical

connections) must be carried out by specialised person-

nel in conformity with the regulations in force.

SAFETY WARNINGS

It is recommended to use flat-bottom pans with a diam-

eter equal to or slightly larger than that of the heated

area. Do not use pans with a rough base to prevent

scratching the heat surface of the cooktop (Fig.2).

This appliance is not suitable for use by children or

persons requiring supervision. Do not let children play

with the appliance.

Before connecting the appliance to the electricity sup-

ply:

- Check that the voltage and power values listed on the

data plate (positioned on the lower part of the appliance)

are compatible with the electricity supply and socket. If

you have any doubts, please consult a qualified electri-

cian for assistance.

IMPORTANT

- Avoid spilling liquid, therefore to boil or heat

liquids, reduce the heat.

- Do not leave the heating elements on with empty

pots and pans or without receptacles.

- When you have finished cooking, switch off the

relevant heating element with the control indicated

below.

WARNING: Steam cleaners must not be used.

WARNING: If the surface is cracked, switch off the

appliance to prevent electric shock.

This appliance conforms to the European Directive EC/

2002/96, Waste Electrical and Electronic Equipment

(WEEE). By making sure that this appliance is disposed

of in a suitable manner, the user is helping to prevent

potential damage to the environment or to public health.

The

symbol on the product or on the accompanying

paperwork indicates that the appliance should not be

treated as domestic waste, but should be delivered to a

suitable electric and electronic appliance recycling col-

lection point. Follow local guidelines when disposing of

waste. For more information on the treatment, re-use and

recycling of this product, please contact your local au-

thority, domestic waste collection service or the shop

where the appliance was purchased.

INSTALLATION INSTRUCTIONS

These instructions address specialised installers and

serve as a guide for installation, adjustment and mainte-

nance in conformity with the laws and regulations in

force.

If a built-in oven or any other appliance that generates

heat must be fitted directly under the glass-ceramic

cooktop, THIS APPLIANCE (oven) AND THE GLASS-

CERAMIC COOKTOP MUST BE SUITABLY INSULATED

in such a way that the heat generated by the oven,

measured on the bottom right of the cooktop, does not

exceed 60°C. Failure to respect this precaution may

determine improper functioning of the TOUCHCONTROL

system.

POSITIONING (Fig.1)

The domestic appliance is designed to be built into a

worktop as illustrated in the specific figure. Apply seal-

ant around the entire perimeter (cut-out dimensions

Fig.1B).

Fix the domestic appliance on the worktop by means of

the 4 brackets provided, taking the thickness of the

worktop into account (Fig.1A). If the lower part of the

appliance, after installation, is accessible via the lower

part of the cabinet then it is necessary to mount a

separator panel respecting the distances indicated

(Fig.1C). If the appliance is installed with an oven under-

neath then the separator is not necessary.

ELECTRICAL CONNECTIONS

Before making the electrical connections, check that:

- the ground cable is 2 cm longer than the other cables;

- the system ratings meet the ratings indicated on the

identification plate fixed on the lower part of the worktop;

- the system is fitted with efficient earthing compliant to

the laws and regulations in force.

Earthing is obligatory by law.

If the domestic appliance is not fitted with a cable and/

or relevant plug, use material suited to the absorption

value indicated on the identification plate and the oper-

ating temperature. At no point must the cable reach a

temperature 50°C higher than room temperature.

If wishing to make a direct connection to the mains, an

omnipolar switch must be interposed with a minimum

opening of 3 mm between the contacts and suited to the

load indicated on the plate and conform to the regula-

tions in force (the yellow/green ground conductor must

not be interrupted by the switch). When the appliance

has been installed, the omnipolar switch must be easily

reachable.

USE AND MAINTENANCE

MAINTENANCE

Remove any residues of food and drops of grease from

the cooking surface using the special scraper supplied

on request (Fig.3)

Clean the heated area as thoroughly as possible using

SIDOL, STAHLFIX or similar products and a cloth/paper,

then rinse with water and dry with a clean cloth.

Using the special scraper (optional) immediately remove

any fragments of aluminium and plastic material that

have unintentionally melted on the heated cooking area

or residues of sugar or food with a high sugar content

(Fig.3). In this way, any damage to the cooktop surface

is prevented.

Under no circumstances use abrasive sponges or irritat-

ing chemical detergents such as oven sprays or stain

removers.
