CAUTION
Whenever the product has been lying horizontally during transportation, it should be
left to stand upright for at least six hours before it is switched on, otherwise it may be
noisy when it is in operation.
Before plugging the appliance in, make sure that the power supply voltage corresponds
to the value shown on the product data plate (“See the section Electrical connection”).
Plug the appliance into the electricity mains supply. The display will ash, showing the
default temperature set by the manufacturer (-16°C). After a few seconds, the display
will show the actual temperature of the refrigerator compartment. If the symbol “--”
appears on the display, the appliance is plugged in, but switched o.
SWITCHING ON THE APPLIANCE
The product is turned on by touching the ( ) symbol for 0.5 seconds, action followed
by an audible signal (1 beep).
During operation, the temperature inside the refrigerator appears on the display,
which can indicate temperature values of between +20°C and -40°C. Temperatures of
over +20°C inside the refrigerator (for example, +21°C), are indicated on the display
by the letter “H”: The temperature may be set to a value between -16°C and -24°C.
The product is turned o by touching the (
) symbol for 5 seconds, followed by an
audible signal (2 beeps) and two dash (--) on the display.
STARTING THE APPLIANCE
8
STANDARDS-WARNINGS AND RECOMMENDATIONS
REMOVAL OF PACKAGING POSITIONING AND INSTALLING THE APPLIANCE
Place the appliance in its installation site (chap. POSITIONING AND INSTALLINGTHE
APPLIANCE).
• Cut straps R and remove the box or plastic bag С (g. 2).
• Immediately destroy the plastic bags S as they could be dangerous for children.
• Once the appliance is free from its packaging, remove the side protections Fand
then the base B.
PACKAGING
Packaging material is 100% recyclable. For its disposal follow your local regulations.
The packaging material (plastic bags, polystyrene parts etc.) must be kept out
ofchildren’s reach as it could be dangerous.
PRODUCT
Scrapping must be carried out according to your local regulations on the disposal
ofwaste materials. Before scrapping the appliance, cut the electrical supply cable so
thatit can no longer be used. The appliance must not be left in the environment, it
must behanded over to a collection center specialized in the recovery of refrigerating
gasesand lubricating oils.
REMOVING THE TRANSPORT PROTECTION
DEVICES
Check that the appliance is undamaged.
The retailer must be informed of any damage to the appliance within 24 hours
ofdelivery.
Remove the protection from the door gasket.
The protection is used to protect the gasket during transport.
The protection must be removed in order to ensure that the door seal functionscorrectly.
To remove the protection, lightly pull one end while rotating it outwards.
SPARE PARTS SUPPLIED
A. Instruction manual
B. Ice tray
TECHNICAL SPECIFICATIONS
• CARRYING STRUCTURE
Made of electrostatically treated and painted plate panels to resist heavy duty wearand
tear and keep its beautiful sine as well.
• INSULATION
Selected to keep internal temperature constant and to give large internal spaces.
• FREEZER DEFROSTING
Automatic
• FREEZER COMPARTMENT TEMPERATURE CONTROL: Electronic.
• INFORMATION
This appliance is CFC-free (it the refrigerating circuit contains R134a) or HFC-free(if the
refrigerating circuit contains R600a Isobutane).
For more details, see matriculation plate inside the appliance.
The dry ventilation air cools food more quickly; thus the NO FROST technique
has been applied to keep chilling more regular.
WARNING! When you install your appliance, it is important to bear inmind
the climatic rating of the appliance. In order to nd out the climaticrating
of your appliance check the data rating plate.
LEVELLING THE APPLIANCE
Make sure that the appliance is on level.
Adjust the front feet P if necessary (Fig. 7-8).
ELECTRICAL CONNECTION
• The electrical wiring must comply with the norms on electrical safety.
• Check that the voltage on the rating plate corresponds to the voltage in your
home.
• The appliance must have an earth according to the laws in force. The
manufacturerdeclines all responsibility for any damage to persons, animals or
things as a resultof failure to comply with these norms.
• If the plug and the socket are not of the same kind, ask a qualied technician
tochange the plug.
WARNING!
Do not use adaptors, multiple sockets or extensions (Fig. 10).
IMPORTANT! If the appliance is switched o and then immediately
switched on again, the compressor activates after about 10 minutes. This
is a normal operating procedure for the appliance.
1 GREEN AND YELLOW EARTH
2 BLUE NEUTRAL
3 BROWN LIVE
4 13 AMP FUSE
5 CABLE CLAMP
WARNING!
THIS APPLIANCE MUST BE EARTHED.
ON / OFF
DISPLAY FREEZER
TEMPERATURE ADJUSTMENT
SUPER FUNCTION
PRE-ALARM AND TEMPERATURE ALARM
DOOR OPEN ALARM
