9
Secure 2-Port KVM Switch User Manual
ront Panel Features – K202B/K202D
1
2
3
6
4
5
1 – Heavy-duty steel enclosure
2 – Channel #1 selected LED
3 – Channel #1 select push-button
4 – Channel #2 select push-button
5 – Channel #2 selected LED
6 - Holographic Tamper Evident Label
