Kramer K202B [13/22] Product specifications

Secure 2-Port KVM Switch User Manual

Product Specifications

Enclosure Welded steel metal enclosure

Power Requirements 12V DC, 1A (maximum) power

adapter with center-pin-positive

polarity

AC Input 100 to 240VAC

No. of Secure Channels 2

No. of Users Supported 1

No. of Computers Supported 2

Displays Supported 1 single-link DVI-D display; analog

VGA display or HDMI with adapter

(K202B only)

Resolution Support Up to 1920x1200 DVI, up to

2048x1536 VGA (K202B only)

Console Keyboard Input USB Type-A female connector

Console Mouse Input USB Type-A female connector

Console Audio Out 3.5mm stereo jack

CPU Keyboard/Mouse Ports USB Type-B jack

CPU Audio Input 3.5mm stereo jack

CPU Video Input Port DVI-I dual-link female

Port Select push-buttons 2

Channel select LED Indicators 2

Operating Temp 32° to 104° F (0° to 40° C)

Storage Temp -4° to 140° F (-20° to 60° C)

Humidity 0 - 80% RH, non-condensing

Warranty 2 years; can be extended to up to 7

years at cost.

Dimensions 136(W) x 615 (D) x 36 (H) mm / 5.4

(W) x 24.6 (D) x 1.46 (H) inch

Weight 0.36 Kg. (0.8 lbs.)

Security Accreditation Common Criteria

Product design life-cycle 10 years
