4 Connecting the RC-74DL

Always switch off the power to each device before connecting it to your

RC-74DL. After connecting your RC-74DL, connect its power and then

switch on the power to each device.

To connect the RC-74DL, as shown in Figure 3, do the following:

1. Connect the IR outputs as follows:

 Connect an IR emitter to IR OUTPUT 1 and attach the emitter to the

DVD player

 Connect an IR emitter to IR OUTPUT 2 and attach the emitter to the

power amplifier

2. Connect the RS-232 ports (see Section 4.3) as follows:

 Connect RS-232 port 1 to the projector

 Connect RS-232 port 3 to the plasma display

3. Connect the RELAY terminal block connectors as follows:

 Connect RELAY 1 and 2 to the screen

 Connect RELAY 3 and 4 to the lighting system

4. Connect the GPI/O 1 port to a motion detector.

5. Connect the Ethernet port to a network (not shown in Figure 3).

6. Connect the K-NET port to any RC device with K-NET (for example, the

RC-63DL).
