Kramer RC-74DL [20/22] Technical specifications

RC-74DL - Technical Specifications

7 Technical Specifications

INPUTS:

3 RS-232, 1 RS-485, 2 GPI/O and 2 K-NET on terminal

block connectors; Ethernet on an RJ-45 connector; 1

infrared sensor, 1 USB for programming

OUTPUTS:

2 IR, 4 relays (36V AC or DC, 2A, 60VAC maximum on

non-inductive load) and 2 GPI/O on terminal block

connectors

DEFAULT IP SETTINGS:

IP number  192.168.1.39; Mask – 255.255.0.0; Gateway

– 0.0.0.0

POWER CONSUMPTION:

12V DC, 570mA

OPERATING TEMPERATURE:

0° to +40°C (32° to 104°F)

STORAGE TEMPERATURE:

-40° to +70°C (-40° to 158°F)

HUMIDITY:

10% to 90%, RHL non-condensing

DIMENSIONS:

16.2cm x 2.6cm x 11.4 (6.4" x 1.0” x 4.5") W, D, H

WEIGHT:

0.6kg (1.4lbs) approx.

INCLUDED ACCESSORIES:

Power supply, Kramer K-Config Windows®-based

configuration software

OPTIONAL ACCESSORIES:

IR emitter cables, KPOD-301, OWB-3G

Specifications are subject to change without notice at http://www.kramerelectronics.com
