4 Connecting the SL-10

Always switch off the power to each device before connecting it to your

SL-10. After connecting your SL-10, connect its power and then switch

on the power to each device.

To connect the SL-10 as illustrated in the example in Figure 2:

1. Connect the RELAY terminal block connectors as follows:

 Connect RELAY 1 and 2 to the projector lift

 Connect RELAY 3 and 4 to the screen

 Connect RELAY 5 to the lighting system

2. Connect the IR outputs as follows:

 Connect an IR emitter to IR OUTPUT 1 and attach the emitter to the

DVD player

3. Connect the GPI/O ports as follows:

 Connect GPI/O 1 to motion detector 1

 Connect GPI/O 2 to motion detector 2

4. Connect the RS-232 ports as follows:

 Connect RS-232 port 1 to the DVD player

 Connect RS-232 port 2 to the projector

5. Connect the IR input as follows:

 Connect IR INPUT 1 to an IR sensor (or alternatively connect IR

INPUT 1 to an external IR receiver

P/N: C- A35M/IRR two extension cables are also available: a 15 meter cable and

a 20 meter cable.

6. Connect the RS-485 to several Kramer matrices, for example.

Not shown in Figure 2.

7. Connect the Ethernet port to a network.
