SL-10 - Overview

3 Overview

The SL-10 is a highly versatile controller that acts as an all-in-one control

processor for control of A/V equipment—especially projectors and associated

equipment—in any room (such as classrooms, boardrooms, or auditoriums).

It streamlines operations and simplifies control by integrating audio, video, and

computer-video sources into a centralized system.

The SL-10 features:

 An Ethernet port for controlling several AV products over ETH

 2 general purpose I/O ports that can be configured as analog inputs, digital

inputs, or digital outputs for interfacing with a variety of devices such as

sensors, switches, LEDs, and relays

 2 bidirectional RS-232 ports that control AV equipment such as projectors,

LCD and PDP displays, power amplifiers, switchers and scalers

 5 relay contact closure ports that control other room items related to the AV

system such as raising and lowering drapes, the screen or the projector

 IR control on two inputs (one built-in receiver and the other on a 3.5mm mini

jack) and three outputs (on terminal blocks)

 IR Learning that learns commands from any IR remote

 1 RS-485 serial port

 Compatibility with Kramer Site-CTRL software for network remote control

and management over the Ethernet port

 A K-NET™ control channel that connects compatible user interfaces and

supplies power and control data over a single cable

 A USB port for uploading a configuration file

 Status LEDs for all functions

 Flexible control via Ethernet, K-NET™, RS-485, an IR sensor and external

IR commands
