Connecting the PC/Audio Line Transmitter/Receiver

5.2 Connecting Multiple Devices

To connect multiple units in a chain as shown in

Figure 4, do the following:

1. Connect the TP-100AXR to the source, as explained in section

5.1.

2. Connect the LINE OUT 1 RJ-45 connector on the TP-100AXR to the

LINE IN RJ-45 connector on the first TP-200AXR.

3. Connect the LINE LOOP OUT RJ-45 connector on the first TP-200AXR

to the LINE IN on the next TP-200AXR.

4. Repeat this connection for all remaining units in the line.

5. On the last TP-200AXR press in the termination pushbuttons. Do not

terminate the devices in the middle of the line.

6. A similar chain can be connected to the LINE OUT 2 RJ-45 connector on

the TP-100AXR.

7. Connect the 12V DC power adapters to the power sockets and connect the

adapters to the mains electricity on all the units

Notes:

• Multiple TP-100AXR units can be connected on a UTP line no

longer than 200m

• The number of units connected depend on the required line quality

• The lines do not have to be of equal length or configuration

1 Alternatively, you can connect the power supply to some of the units so that others are powered via the Power Connect

feature (see section

3.3). Feeding more than three units from each power supply is not recommended. As an example, the

system in

Figure 4, could be powered by two power supplies
