Overview
5
5
3.5 Recommendations for Achieving the Best Performance
To achieve the best performance:
• Use only good quality connection cables
1
• Avoid interference from neighboring electrical appliances that
may adversely influence signal quality and position your Kramer
product away from moisture, excessive sunlight and dust
to avoid interference,
deterioration in signal quality due to poor matching, and elevated
noise levels (often associated with low quality cables).
1 Available from Kramer Electronics on our Web site at http://www.kramerelectronics.com
