Instructions for the user

7. USE OF THE COOKING HOB

7.1 Hobs with knobs

7.1.1 Single cooking zones

Each knob shows the cooking zone it is for.

For example, the symbol

identifies the knob that

controls the rear right-hand cooking zone.

To heat, turn the knob to the desired position (1 to 6).

Adjustment is continuous so that the appliance also

operates at any intermediate value.

7.1.2 Dual cooking zones

Each knob shows the cooking zone it is for.

For example, the symbol

identifies the knob that controls the rear right-hand

cooking zone.

To heat the inner cooking zone, turn the knob to the desired position (1 to 6).

To heat both the inner and outer cooking zones, turn the knob to

and then

release. The knob will thus return to 9. To adjust heating intensity, rotate the

knob anticlockwise to the desired position. To return to heating of the inner

cooking zone only, set the knob back to 0 and then turn to the desired position

(1 to 6).

7.1.3 Description of symbols

REAR LEFT

REAR RIGHT

FRONT LEFT

FRONT RIGHT

7.1.4 Residual heat

The 4 warning lights located between the cooking zones come on when the temperature

of one or more of the zones exceeds 60°C.

The lights go off upon temperature dropping to below approximately 60°C.

7.1.5 Switching off

To turn off, return the knob to 0.
