5 Installing the TBUS-201xl

To install the TBUS-201xl perform the following steps:

1. Cut an opening in the table (see Section 5.1).

2. Install the power socket (see Section 5.2).

3. Insert the TBUS-201xl through the cut-out opening (see Section 5.3).

4. Connect the cables (see Section 5.4).

5.1 Cutting an Opening

The metal cutout template (supplied) defines the surface you have to cut out to

install your TBUS-201xl.

The thickness of the table should be 3in (76mm) or less.

To cut an opening in the table:

1. Before cutting the opening, confirm the dimensions of the cutout template

and make sure that they have not changed.

2. Place the included cut out template (that is included with your TBUS-201xl)

on the surface of the table exactly where you want to install the

TBUS-201xl.

3. Attach the template to the table with the included screws (if using the cut out

template).

4. Following the inside edge of the template, cut a hole in the table surface

with a sabre or keyhole saw according to the dimensions shown in Figure 4

(not to scale).
