10 TBUS-202xl - Installing the TBUS-202xl
5 Installing the TBUS-202xl
To install the TBUS-202xl perform the following steps:
1. Cut an opening in the table (see
Section 5.1
2. Install the power socket (see
).
Section 5.2
3. Insert the TBUS-202xl through the cut-out opening and fix to the table (see
).
Section 5.3
4. Connect the cables (see
).
Section 5.4
5.1 Cutting an Opening
).
The metal cutout template (supplied) defines the surface you have to cut out to
install your TBUS-202xl.
The thickness of the table should be 3in (76mm) or less.
To cut an opening in the table:
1. Before cutting the opening, confirm the dimensions of the cutout template
and make sure that they have not changed.
2. Place the included cut out template (that is included with your TBUS-202xl)
on the surface of the table exactly where you want to install the
TBUS-202xl.
3. Attach the template to the table with the included screws (if using the cut out
template).
4. Following the
inside edge of the template, cut a hole in the table surface
with a sabre or keyhole saw according to the dimensions shown in
Figure 5
(not to scale).
i
