12
UTBUS-1xl - Technical Specifications of the Assembled UTBUS-1xl
6 Technical Specifications of the Assembled
UTBUS-1xl
POWER SOURCE
(AC power limits):
Power Socket Assemblies
Universal
100-240V AC, 50/60Hz, 5A
Maximum 5A per power outlet
Fully compatible with power plugs in the UK, India, Italy and
Denmark, as well as with the 2-prong Europlug.
Partially compatible (if the polarity is reversed) with plugs in
China, Switzerland, Israel and the USA. The universal socket
does not supply grounding to plugs in Central Europe and
France (you should order country specific sockets instead).
Not compatible with South African plugs.
USA
100-120V AC, 50/60Hz, 5A
Maximum 5A/2.5A per power outlet
Germany and EU
100-240V AC, 50/60Hz, 5A
Maximum 5A/2.5A per power outlet
Belgium and France
100-240V AC, 50/60Hz, 5A
Maximum 5A/2.5A per power outlet
Italy
100-240V AC, 50/60Hz, 5A
Maximum 5A/2.5A per power outlet
Switzerland
100-240V AC, 50/60Hz, 5A
Maximum 5A/2.5A per power outlet
UK
100-240V AC, 50/60Hz, 5A
Maximum 5A/2.5A per power outlet
South Africa
100-240V AC, 50/60Hz, 5A
Maximum 5A/2.5A per power outlet
Australia
100-240V AC, 50/60Hz, 5A
Maximum 5A/2.5A per power outlet
Israel
220V AC, 50/60Hz, 5A
Maximum 5A/2.5A per power outlet
FUSE RATING:
T 6.3A 250V
OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
250.2mm x 137.5mm x 65mm (9.85" x 5.41" x 2.56") W, D, H
WEIGHT:
0.7kg (1.54lbs) approx.
ACCESSORIES:
Power cord, self-locking ties, wood screws
OPTIONS:
Passive wall plates and interfaces, power socket kits,
power cord
Specifications are subject to change without notice at http://www.kramerelectronics.com
