Operating the 906

6 Operating the 906

You can operate your 906 using:

• The front panel buttons (see section

6.1)

• PC, touch screen system, or other serial controller via RS-232

serial commands (see section

6.2)

• The Ethernet via the embedded Web server (see section

6.3)

6.1 Using the Front Panel Buttons

The front panel buttons let you:

• Select an input, by pressing the INPUT 1 or the INPUT 2 button

• Adjust the sound

To adjust the sound of the output signal:

1. Press the sound component that you want to adjust (LOUD, BASS, MID,

TREBLE, BAL or VOLUME). The button illuminates.

2. Turn the adjustment knob to adjust the value.

Note: To enable remote volume control via the 10V VOL connector (using

for example, the Kramer RC-63A), you must disable the local digital

volume control by pressing and holding the VOLUME button on the front

panel for several seconds. The LED flashes to indicate that remote control is

enabled. In this mode, volume control via software ("Set simple audio

volume" P3000 command, see section

9.6) is disabled. To disable remote

control, press and hold the VOLUME button and the LED lights solid.

6.2 Using Serial Commands

To operate your device using serial commands, you need to install Kramer's

control software

For an explanation of all control commands, see section

6.3 Using the Embedded Web Server

You can remotely operate the 906 using a Web browser via the Ethernet

connection (see section

5.3). To be able to do so, you must use a supported

Web browser; Microsoft (V6.0 and higher), Chrome or Firefox (V3.0 and

higher).

1 Download control software from our Web site at http://www.kramerelectronics.com
