Pioneer RS-A7 [121/142] Technische gegevens
![Pioneer RS-A7 [121/142] Technische gegevens](/views2/1001567/page121/bg79.png)
Technische gegevens
ALGEMEEN
Spanningsbron
...... 14,4 V gelijkstroom (10,8 — 15,1 V toelaatbaar)
Aarding ............................................ Negatief geaard type
Max. stroomverbruik
(Opgegeven uitgangsvermogen) ........................ 31 A
(Geen signaal) ...................................................... 5 A
Gemiddeld stroomverbruik
(4 kanalen, 4 Ω) .................................................. 12 A
(2 kanalen, 4 Ω) .............................................. 16,5 A
Zekering .............................................................. 25 A × 2
Afmetingen ........................ 330 (b) × 71 (h) × 585 (d) mm
Gewicht ...................................................................... 13 kg
EINDVERSTERKER
Max. vermogen (14,4 V)
...................................... 100 W × 4 / 300 W × 2 (4 Ω)
Continu vermogen (14,4 V)
.................................................. 50 W × 4 / 150 W × 2
(20 - 20k Hz, 0,02/0,02% (4 Ω))
...................................................................... 75 W × 4
(20 - 20k Hz, 0,02% (2 Ω))
Frequentierespons ............ 10 Hz — 100 kHz (+0, –1 dB)
Vervorming ........................ 0,002% (1 kHz, 20 kHz LPF)
Signaal-ruisverhouding .............. 105 dB (IHF-A netwerk)
Scheiding .......... 80 dB (100 Hz — 10 kHz, 20 kHz LPF)
Slew rate ........................................................ 100 V/µ sec.
Dumping factor ............................................................ 150
Impedantie .................................................. 4 Ω (2 — 8 Ω)
Bemonsteringsfrequentie .................................... 44,1 kHz
Digitale ingangsaansluiting ............................ Optische (2)
Opmerking:
• Technische gegevens en ontwerp kunnen zonder
voorafgaande kennisgeving gewijzigd worden ten
behoeve van verbeteringen.
