17
Installation
ATTENTION
• Ne pas installer :
—à un endroit où il risque de blesser le conducteur ou les passagers si le véhicule s’arrête brutalement.
—à un endroit où il risque de gêner le conducteur, par exemple par terre devant le siège.
• Assurez-vous que les fils ne risquent pas de se prendre dans les glissières des sièges, ce qui provoquerait un
court-circuit.
• Assurez-vous qu’aucune pièce ne se trouve derrière le panneau lorsque vous percez un trou pour installer
l’amplificateur. Protégez tous les câbles et équipements importants tels que l’arrivée d’essence, les câbles de
frein et les câbles électriques.
• Installez les vis taraudeuses de façon à ce que la pointe ne touche aucun fil. Il est en effet important de pro-
téger les fils et d’éviter qu’ils ne finissent par se couper à cause des vibrations de la voiture ; cela peut
déclencher une ignition.
• Pour éviter les chocs électriques, n’installez pas l’amplificateur là où il risque d’être en contact avec des liq-
uides.
• Pour garantir une installation correcte, utilisez les pièces fournies en respectant les consignes. Toute autre
pièce que celles qui sont fournies risque d’endommager des composants internes de l’amplificateur ou de se
desserrer, ce qui empêcherait l’appareil de fonctionner.
Pour éviter les dysfonctionnements
• Pour assurer une dissipation de chaleur correcte de l’amplificateur, respectez les consignes suivantes pour
l’installation.
—Laissez assez d’espace au-dessus de l’amplificateur pour la ventilation.
—Ne recouvrez pas l’amplificateur d’un matériau de sol ou d’un tapis.
• N’installez pas l’amplificateur près d’une portière, où il risquerait d’être mouillé.
• N’installez pas l’amplificateur sur un support instable tel que le porte-roue de secours.
• Le meilleur emplacement pour l’installation varie selon le modèle de voiture et l’endroit choisi dans
l’habitacle. Fixez l’amplificateur sur un endroit suffisamment rigide.
• Commencez par faire des branchements temporaires afin de vérifier que l’amplificateur et l’installation
fonctionnent correctement.
• Après avoir installé l’amplificateur, vérifiez que la roue de secours, la prise et les outils peuvent être enlevés
facilement.
