EN_DS4JH57_1214
www.yanmar.eu
MARINE GEARS/DRIVE
Model
Type
Dry Weight
Reduction Ratio [fwd/asn]
Propeller speed [fwd/asn]
Direction of rotation
[propeller shaft - fwd]
Dry weight - engine & gear
Length engine and gear/drive
KM35P
Mechanical cone clutch
15 kg [33 lbs]
2.36/3.16
Clockwise
viewed from stern
235 kg [518 lbs]
870 mm [34 in]
2.61/3.16
1149/9491271/949
ZF30M
Mechanical multi-disc
23 kg [51 lbs]
2.15/2.64
Clockwise
viewed from stern
243 kg [536 lbs]
950 mm [37 in]
1395/1136
2.70/2.64
1111/1136
Saildrive SD60
Mechanical wet type multi-disc
44 kg [97 lbs]
2.23/2.23
Clockwise & counterclockwise
viewed from stern
264 [582 lbs]
1113 mm [44 in]
1345/1345
253 kg [558 lbs]
KM4A1 [down angle: 7º]
Mechanical cone clutch
33 kg [73 lbs]
Clockwise & counterclockwise
viewed from stern
926 mm [36 in]
1.47/1.47
2041/2041
2.14 / 2.14
1402/1402
2.63/2.63
1141/1141
1288/980
KM35A2 [down angle: 7º]
Mechanical cone clutch
16 kg [35 lbs]
2.33/3.06
Clockwise
viewed from stern
236 kg [520 lbs]
868 mm [34 in]
2.64/3.06
1136/980
Output Power, kW
0
5
10
15
20
25
30
35
40
45
50
0
20
40
60
0
20
40
60
80
100
120
140
160
180
800600 1000 1200 1400 1600 1800 2000 2200 2400 2600 2800 3000 3200800600 1000 1200 1400 1600 1800 2000 2200 2400 2600 2800 3000 3200 800 1000 1200 1400 1600 1800 2000 2200 2400 2600 2800 3000 3200600
0
2
4
6
8
10
12
14
Output Power, mhp
Torque, Nm
Fuel Consumption, l/hr
Engine Speed, rpm Engine Speed, rpm Engine Speed, rpm
Torque at Crankshaft
Fuel Consumption at Prop. load exp. 3.0
Crankshaft Torque, lb/ft
20
40
60
80
100
120
Torque at Crankshaft
Fuel Consumption, gal/hr
1
2
3
Max. Output at Crankshaft
Max. Output at Prop. shaft
Propeller power curve (load exp. 3.0)
PERFORMANCE CURVES
Optional
• Second alternator 12V - 125A or 24V - 60A
• High-riser mixing elbow [instead of L-elbow]
• Extension wire harness [3m, 5m, 10m]
• Hot water kit with cocks
• Second station harness and panel
• C35-panel
• Oil pressure sensor for C35-panel
• Extension saildrive leg [75 mm]
• Propeller cone nut kit SD60
• NMEA 2000 convertor for Engine monitory system
• Emergency stop switch
Standard Package
• Set of flexible engine mounts
• Exhaust mixing elbow [L-type]
• V-belt safety cover
• Fresh water expansion tank
• Alternator 12V - 125A
• Operation manual
• B25-panel
• Sensors for instrument panel
• Seawaterpump front mounted
• Engine Topcover for protection
ACCESSORIES
NOTE: All data subject to change without notice. Text and illustrations are not binding.
INSTRUMENT PANELS
180.01 mm [7.087 in]
254.99 mm [10.039 in]
139.95 mm [5.510 in]
139.95 mm [5.510 in]
B25 STANDARD C35 OPTIONAL
2.49/2.49
1205/1205
