EN_DS4JH80_1215
MARINE GEARS/DRIVE
Model
Type
Dry Weight
Reduction Ratio [fwd/asn]
Propeller speed [fwd/asn]
Direction of rotation
[propeller shaft - fwd]
Dry weight - engine & gear
Length engine and gear/drive
KMH4A [down angle: 8º]
Hydraulic, multi disk clutch
33 kg [73 lbs]
2.04/2.04
Clockwise & counterclockwise
viewed from stern
261 kg [575 lbs]
907 mm [35.7 in]
2.45/2.45
1306/13061569/1569
ZF30M
Mechanical multi-disc
25 kg [55 lbs]
2.15/2.64
Clockwise
viewed from stern
254 kg [560 lbs]
925 mm [36.4 in]
1488/1212
2.70/2.64
1185/1212
Saildrive SD60
Mechanical wet type multi-disc
45 kg [99 lbs]
2.23/2.23
Clockwise & counterclockwise
viewed from stern
274 kg [604 lbs]
1150 mm [45.3 in]
1435/1435
263 kg [580 lbs]
KM4A2 [down angle: 7º]
Mechanical cone clutch
33 kg [73 lbs]
Clockwise & counterclockwise
viewed from stern
909 mm [35.8 in]
1.47/1.47
2177/2175
2.14 / 2.14
1495/1494
2.63/2.63
1217/1216
1658/1658
ZF25A [down angle: 8º]
Hydraulic, multi disk clutch
30 kg [66 lbs]
1.93/1.93
Clockwise & counterclockwise
viewed from stern
259 kg [571 lbs]
905 mm [35.6 in]
2.48/2.48
1290/1290
Max. Output at Crankshaft
Max. Output at Prop. shaft
Propeller power curve (load exp. 3.0)
0 0 0
2
4
6
8
10
12
14
16
18
50
100
150
200
250
10
20
40
60
80
20
30
40
50
60
70
600 800 1000 1200 1400 1600 1800 2000 2200 2400 2600 2800 3000 3200 3400 600 800 1000 1200 1400 1600 1800 2000 2200 2400 2600 2800 3000 3200 3400 600 800 1000 1200 1400 1600 1800 2000 2200 2400 2600 2800 3000 3200 3400
Output Power, mhp
Torque, Nm
Fuel Consumption, l/hr
Output Power, kW
Engine Speed, rpm Engine Speed, rpm Engine Speed, rpm
Torque at Crankshaft Fuel Consumption at Prop. load exp. 3.0
Crankshaft Torque, lb/ft
50
100
150
Fuel Consumption, gal/hr
1
2
3
4
PERFORMANCE CURVES
Optional
• Second alternator 12V - 125A or 24V - 60A
• High-riser mixing elbow [instead of L-elbow]
• Extension wire harness [3m, 5m, 10m]
• Hot water kit with cocks
• Second station harness and panel
• C35-panel
• Oil pressure sensor for C35-panel
• Extension saildrive leg [75 mm]
• Propeller cone nut kit SD60
• NMEA 2000 convertor for Engine monitory system
• Emergency stop switch
• Seawaterpump front mounted
Standard Package
• Set of exible engine mounts
• Exhaust mixing elbow [L-type]
• V-belt safety cover
• Fresh water expansion tank
• Alternator 12V - 125A
• Operation manual
• B25-panel
• Sensors for instrument panel
• Engine Topcover for protection
ACCESSORIES
NOTE: All data subject to change without notice. Text and illustrations are not binding.
INSTRUMENT PANELS
180.01 mm [7.087 in]
254.99 mm [10.039 in]
139.95 mm [5.510 in]
139.95 mm [5.510 in]
B25 STANDARD C35 OPTIONAL
2.49/2.49
1285/1285
www.yanmarmarine.com
