ZVE 350 SD

● Work as an USB Disk

Following below steps, users are allowed to download and upload files from the inspection unit to a computer via USB 2.0:

1. Press to turn on the inspection.

2. Connect the inspection to a computer using a USB cable.

3. “USB Disk” will be displayed on the LCD screen, and two portable disk (the internal memory and external Micro SD

card) will be recognized by the computer. The inspection unit now works as an U-disk.

● Video Output to TV

To view real time image from a TV, connect the VIDEO OUT port of the unit with the VIDEO IN port of the TV using a

video cable. LCD screen of the inspection will be turned off when connection established.

● Basic Operations

1. Operations in Preview Mode:

a) Default memory is the internal memory when powered on, users can also use Micro SD card as external memory.

When a Micro SD card detected, the inspection will store files in the external memory.

b) Press to enter preview mode in which users can preview images.

c) Press to increase the brightness of LED lights.

d) Press to decrease the brightness of LED lights.

e) Press to take pictures manually, files will be stored in internal memory or Micro SD card automatically. (Note: when

Auto Capture is OFF, press to take a picture; when Auto Capture is ON, unit will detect image changes and pictures

will be taken and saved automatically if any changes detected)

f) Press to record video clips, a read indicator will be displayed on screen, and clips will be saved in internal memory or SD card.

g) Press to rotate the image by 180 degrees.

h) Press to zoom in from x1 to x4.0, and the corresponding magnification will be displayed on screen.
