ZVE 350 SD

i) Press to zoom out, the corresponding magnification will be displayed on screen; no magnification will be

displayed when the magnification is x1.

k) Press MENU to configure menu options

l) Press to enter playback mode(message will show up if no files found)

m) Press and hold for 3 seconds to turn off.

Tips: 1) when the probe is not installed and no signal is received, unit will shut off itself in 3 minutes.

2) A folder named “YCKC” will be created in the internal memory or TF card in which the product will create a subfolder named

as the current date. Videos and photos captured for the day will be saved in this folder.

Warning: DO NOT remove the SD card while system is working(especially while recording and transferring files with computers),

doing so may result in damage to stored files and SD card.

2. Menu Configuration

a. Press MENU key in preview mode to enter menu configurations;

b. Select to be changed options using the 4 direction keys;

c. Press MENU to confirm the changed option;

d. Press to return to parent menu, and all the way back to preview mode.

e. Menu Instructions (highlighted options are factory default settings):

Auto Capture

Auto Capture ON; OFF

Master Ch. Photo 1; Photo 3; Movie 5s; Movie 10s

Range 1/1; 1/4; 1/16

Timeslot 1s; 3s; 5s

Sensitivity Low; Middle; High
