Hardwiring
Wiring must be performed by a qualified electrician.
1. Install a utility circuit breaker in accordance with local electrical codes (see tables below) for
input wiring.
2. Switch the UPS input circuit breaker (see A) and utility circuit breakers OFF.
3. Remove the access panel (see B).
4. Remove circular knockouts.
5. Run wires through access panel to terminal blocks. Wire to ground block first. Adhere to all
national and local electrical codes. (See tables and graphics.)
6. Use appropriate strain-relief on the hardwired input and output power cables.
XLT, XLJ, AND XLTW MODELS
Input Connection Output Connection (optional)
Wire to L1, L2, and .
Wire to L1A, L2A, and
.
System Wiring Voltage Current
Full Load
(Nominal)
External Input Circuit
Breaker (typical)
Wire Size
(typical)
SURT8000XLJ,
SURT8000XLT,
SURT8000XLTW
Input &
Output
200/208/220/240 V 40 A 50 A / 2-pole
for Input Wiring only
10mm
2 *
#8 AWG
SURT10000XLJ,
SURT10000XLT,
SURT10000XLTW
Input &
Output
200/208/220/240 V XLJ-50 A
XLT-48 A
XLTW-48 A
60 A or 63 A / 2-pole
for Input Wiring only
16mm
2 *
#6 AWG
XLI MODELS
Input Connections Output Connection (optional)
Single-Phase: Wire to L1, N, and .
Three-Phase: Wire to L1, L2, L3, N, and
.
Wire to L1A, N1, and
.
System Wiring Number
of
Phases
Voltage Current
Full Load
(Nominal)
External Input
Circuit Breaker
(typical)
Wire Size
(typical)
Input 1 220/230/240 V 40 A 50 A / 2-pole 10mm
2 *
Input 3+
Neutral
380/400/415 V 15 A / phase when
online
40 A on L1 in bypass
50 A / 4-pole 10mm
2 *
SURT8000XLI
Output 1 220/230/240 V 40 A (not required) 10mm
2 *
Input 1 220/230/240 V 50 A 63 A / 2-pole 16mm
2 *
Input 3+
Neutral
380/400/415 V 18 A / phase when
online
50 A on L1 in bypass
63 A / 4-pole 16mm
2 *
SURT10000XLI
Output 1 220/230/240 V 50 A (not required) 16mm
2 *
* Recommended wire sizes are typical. Actual wire size must comply with required ampacity
and local and national electrical codes.
