42
Consumer Infrared Module Header This header can be used to
(4-pin CIR1)
connect the remote
(see p.14 No. 27)
controller receiver.
Serial port Header This COM1 header supports a
(9-pin COM1)
serial port module.
(see p.14 No. 31)
