ASRock 990fx extreme9 [44/78] Smart switches
![ASRock 990fx extreme9 [44/78] Smart switches](/views2/1159411/page44/bg2c.png)
44
Power
Reset
2.11 Smart Switches
The motherboard has three smart switches: power switch, reset switch and clear
CMOS switch, allowing users to quickly turn on/off or reset the sytem clear the
CMOS values.
Power Switch Power Switch is a smart switch,
(PWRBTN)
allowing users to quickly turn
(see p.14 No. 21)
on/off the system.
Reset Switch Reset Switch is a smart switch,
(RSTBTN)
allowing users to quickly reset
(see p.14 No. 22)
the system.
Clear CMOS Switch Clear CMOS Switch is a smart
(CLRCBTN)
switch, allowing users to quickly
(see p.15 No. 18)
clear the CMOS values.
