58
Voltage Conguration
CPU Load-line calibration
Use this to select CPU Load-line calibration. The default value is [Auto].
DRAM Voltage
Use this to select DRAM Voltage. The default value is [Auto].
NB Voltage
Use this to select NB Voltage. The default value is [Auto].
HT Voltage
Use this to select HT Voltage. The default value is [Auto].
CPU VDDA Voltage
Use this to select CPU VDDA Voltage. The default value is [Auto].
PCIE VDDA Voltage
Use this to select PCIE VDDA Voltage. The default value is [Auto].
