67
USB Phy Power Down
Use this item to enable the USB PHY to power down in S4/S5 state.
USB Keyboard/Remote Power On
Use this item to enable or disable the system to wake from S5 using USB
Keyboard/Remote.
USB Mouse Power On
Use this item to enable or disable the system to wake from S5 using USB
Mouse.
CSM
Please disable CSM when you enable Fast Boot option. The default value
is [Enabled].
