35
North Bridge Maximum Frequency
It will display North Bridge Maximum Frequency for reference.
Processor Maximum Voltage
It will display Processor Maximum Voltage for reference.
Multiplier/Voltage Change
This item is set to [Auto] by default. If it is set to [Manual], you may adjust
the value of Processor Frequency and Processor Voltage. However, it is
recommended to keep the default value for system stability.
BIOS SETUP UTILITY
Main
Advanced H/W Monitor Boot Security Exit
Overclocking may cause
damage to your CPU and
motherboard.
It should be done at
your own risk and
expense.
Select Screen
Select Item
Enter Go to Sub Screen
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
v02.54 (C) Copyright 1985-2005, American Megatrends, Inc.
OC Tweaker
CPU Configuration
CPU Frequency (MHz)
PCIE Frequency (MHz)
[400]
[100]
Processor Maximum Frequency
North Bridge
Processor Maximum Voltage
Maximum Frequency
x31.5 6300 MHZ
x31.0 62
1.5500 V
00 MHz
Spread Spectrum
Boot Failure Guard
Boot Failure Guard Count
Advanced Clock Calibrati on
[Auto]
[Enabled]
[3]
[Disabled]
HT Bus Speed
HT Bus Width
[Auto]
[Auto]
Memory Configuration
Memory Clock
[Auto]
Overclock Mode
[Auto]
Multiplier/Voltage Change
[Manual]
CPU Frequency Multiplier
For safety and system stability, it is not recommended to adjust the value
of this item.
Processor Voltage
It allows you to adjust the value of processor voltage. However, for safety
and system stability, it is not recommended to adjust the value of this item.
NB Frequency Multiplier
For safety and system stability, it is not recommended to adjust the value
of this item.
HT Bus Speed
This feature allows you selecting Hyper-Transport bus speed.
HT Bus Width
This feature allows you selecting Hyper-Transport bus width.
Memory Conguration
Memory Clock
This item can be set by the code using [Auto]. You can set one of the stan-
dard values as listed for DDR2 memory modules: [200MHz DDR2_400],
[266MHz DDR2_533], [333MHz DDR2_667] and [400MHz DDR2_800]. If
you adopt Phenom CPU, there is one more option: [533MHz DDR2_1066].
