3.4.4 Storage Conguration
Onboard SATA Controller
Use this item to enable or disable the “Onboard SATA Controller” feature.
SATA Operation Mode
Use this item to adjust Onboard SATA Operation Mode. The default value
of this option is [AHCI]. Conguration options: [AHCI], [IDE] and [RAID].
If you set this item to RAID mode, it is suggested to install SATA ODD
driver on SATAII_5 (PORT 4) and SATAII_6 (PORT 5) ports.
SATA IDE Combined Mode
This item is for SATAII_5 (PORT 4) and SATAII_6 (PORT 5) ports. Use this
item to enable or disable SATA IDE combined mode. The default value is
[Enabled].
If you want to build RAID on SATAII_5 (PORT 4) and SATAII_6 (PORT 5)
ports, please disable this item.
BIOS SETUP UTILITY
Storage Configuration
v02.54 (C) Copyright 1985-2003, American Megatrends, Inc.
Advanced
Onboard SATA Controller
SATA Operation Mode
SATA IDE Combined Mode
IDE1 Master
SATAII_1
SATAII_2
SATAII_3
SATAII_4
IDE1 Slave
SATAII_5
SATAII_6
[Enabled]
[AHCI]
[Enabled]
[Hard Disk]
[Not Detected]
[Not Detected]
[Not Detected]
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
Configure onboard
serial ATA
controller.
