46
3.4.7 Super IO Conguration
OnBoard Floppy Controller
Use this item to enable or disable oppy drive controller.
Serial Port Address
Use this item to set the address for the onboard serial port. Conguration
options: [3F8 / IRQ4] and [3E8 / IRQ4].
Infrared Port
Use this item to enable or disable the onboard infrared port.
Infrared Port Address
Use this item to set the address for the onboard infrared port.Conguration
options: [2F8 / IRQ3] and [2E8 / IRQ3].
BIOS SETUP UTILITY
Configure Super IO Chipset
A llow BIOS to Enable
o r Disable Floppy
C ontroller.
S elect S creen
S elect I tem
+ - C hange Option
F 1 G eneral Help
F 9 L oad Defaults
F 10 S ave and Exit
E SC E xit
v02.54 (C) Copyright 1985-2003, American Megatrends, Inc.
Advanced
O nBoard Floppy Controller
S erial Port A ddress
I nfrared Port Address
[ Disabled]
[ 3F8/IRQ4]
[ Disabled]
