ASRock z170 extreme7+ [57/99] Setting
![ASRock z170 extreme7+ [57/99] Setting](/views2/1159490/page57/bg39.png)
51
English
Z170 Extreme7+
3.3.4 Setting
In the "Setting" page, you can change the language, select the server location, and
determine if you want to automatically run the ASRock Live Update & APP Shop
on Windows startup.
