ASRock h110m-gl/d3 [18/69] Installing memory modules dimm
![ASRock h110m-gl/d3 [18/69] Installing memory modules dimm](/views2/1159580/page18/bg12.png)
14
English
2.3 Installing Memory Modules (DIMM)
is motherboard provides two 240-pin DDR3/DDR3L (Double Data Rate 3)
DIMM slots, and supports Dual Channel Memory Technology.
e DIMM only ts in one correct orientation. It will cause permanent damage to the
motherboard and the DIMM if you force the DIMM into the slot at incorrect orientation.
1. For dual channel conguration, you always need to install identical (the same brand,
speed, size and chip-type) DDR3/DDR3L DIMM pairs.
2. It is unable to activate Dual Channel Memory Technology with only one memory module
installed.
3. It is not allowed to install a DDR or DDR2 memory module into a DDR3/DDR3L slot;
otherwise, this motherboard and DIMM may be damaged..
