Voltage Confi guration
DRAM Voltage
Use this to select DRAM Voltage. The default value is [Auto].
FCH Voltage
Use this to select FCH Voltage. The default value is [Auto].
+1.8V Voltage
Use this to select +1.8V Voltage. The default value is [Auto].
+1V Voltage
Use this to select +1V Voltage. The default value is [Auto].
User Default
In this option, you are allowed to load and save three user defaults
according to your own requirements.
