1. Introduction
Thank you for purchasing ASRock 990FX Extreme4 motherboard, a reliable moth-
erboard produced under ASRock’s consistently stringent quality control. It delivers
excellent performance with robust design conforming to ASRock’s commitment to
quality and endurance.
In this manual, chapter 1 and 2 contain introduction of the motherboard and step-
by-step guide to the hardware installation. Chapter 3 and 4 contain the con guration
guide to BIOS setup and information of the Support CD.
Because the motherboard speci cations and the BIOS software might
be updated, the content of this manual will be subject to change without
notice. In case any modi cations of this manual occur, the updated ver-
sion will be available on ASRock website without further notice. You may
nd the latest VGA cards and CPU support lists on ASRock website as
well. ASRock website http://www.asrock.com
If you require technical support related to this motherboard, please visit
our website for speci c information about the model you are using.
www.asrock.com/support/index.asp
1.1 Package Contents
ASRock 990FX Extreme4 Motherboard
(ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm)
ASRock 990FX Extreme4 Quick Installation Guide
ASRock 990FX Extreme4 Support CD
1 x ASRock SLI_Bridge_2S Card
1 x 80-conductor Ultra ATA 66/100/133 IDE Ribbon Cable
1 x Ribbon Cable for a 3.5-in Floppy Drive
4 x Serial ATA (SATA) Data Cables (Optional)
2 x Serial ATA (SATA) HDD Power Cables (Optional)
1 x 3.5mm Audio Cable (Optional)
1 x I/O Panel Shield
1 x Front USB 3.0 Panel
4 x HDD Screws
6 x Chassis Screws
1 x Rear USB 3.0 Bracket
ASRock Reminds You...
To get better performance in Windows
®
7 / 7 64-bit / Vista
TM
/ Vista
TM
64
bit, it is recommended to set the BIOS option in Storage Con guration
to AHCI mode. For the BIOS setup, please refer to the “User Manual” in
our support CD for details.
