Asus rog maximus vi impact [158/222] Chapter 4

4-10

Chapter 4: Software support

Chapter 4

CPU Strap

Click to apply CPU

Strap settings

Click to save the

adjustment into a

prole

Click to load

the saved

prole

Click to apply the

adjustments

Click to undo the

adjustments

Drag the slider to adjust the

CPU Strap’s BCLK (base

clock) frequency

Click to cancel the

CPU Strap settings
