Asus rog maximus vi impact [201/222] Chapter 4

ASUS MAXIMUS VI IMPACT

4-53

Chapter 4

Synchronizing backup les

After creating a junction point, RAMDisk automatically creates a backup folder in the le’s

original location. Use RAMDisk to manually synchronize updates with these backup les.

Click Synchronize to

update your les
