Condensation
Condensation on the device optics can form
in the following circumstances:
• directly after turning on an electric heater;
• left in a room with high humidity or steam;
• when the player is brought from a cold into a
warm room.
If moisture appears inside the enclosure, the
device operation may become faulty. In such
case disconnect the device from the power
supply and wait an hour for the moisture to
evaporate.
Background noise when viewing TV
programs
When viewing TV programs with the player
turned on (depending on the TV settings),
background noise may occur. This should not
be considered as a player or TV set malfunc-
tion. Set the player to Standby mode when
viewing TV programs.
CAUTION:
• To avoid electric shock hazard, this unit must
not be exposed to water.
• Minimum distances should be provided
around the apparatus for sufficient ventila-
tion.
• Ventilation should not be impeded by cover-
ing the ventilation openings with items, such
as newspapers, table-cloths, curtains, etc.
• No naked flame sources, such as lighted
candles, should be placed on the apparatus.
• Before disposing of the appliance, remove
the batteries and place them in the appropri-
ate battery collection container.
CONTROL SYSTEM
Front Panel
1. POWER button – press it to turn on/off the
unit. The remote control device only works if
this button is activated.
2. SEARCH/TUNE UP button – activates fast
forward playback at X2, X4, X8, X16, X32
speed, in the radio mode – search of the
next radio frequency.
3. SEARCH/TUNE DOWN button – activates
fast reverse playback at X2, X4, X8, X16, X32
speed, in the radio mode – search of the
previous radio frequency.
4. BAND/AM/FM & REPEAT 1/ALL button –
toggles between AM and FM bands in the
radio mode. In the audio playback mode,
repeats one/all folders or tracks.
5. AUDIO button – selects audio recording.
6. DISPLAY button - shows information on the
display during playback. Pressing Display
button shows elapsing and remaining time of
the playback.
7. PHONES jack – to connect one pair of head-
phones.
8. Cassette Record button – recording of audio
signal from another sound source, like radio,
DVD, etc. To start recording, the Play and
Record buttons on the cassette deck must
be pressed simultaneously.
9. Cassette Play button – press to play the
tape.
10. Cassette Fast Rewind button – press to fast
rewind the tape.
11. Cassette Fast Forward button – press to fast
forward the tape and find a desired track on
the tape.
12. Stop/Eject button – press once to stop play-
back or recording, press twice to open the
cassette door.
13. Pause button – to temporarily stop playback.
14. Microphone jack – to connect microphone
15. Microphone Volume Control – adjusts micro-
phone volume (karaoke).
16. Cassette Deck
17. SUBTITLE button – press to show available
subtitle languages.
18. DVD STOP button – press it to stop DVD
playback.
19. PAL/NTSC button – press to toggle between
PAL, NTSC and/or MULTI , depending on
your TV system.
20. VOLUME knob – turn clockwise to increase
the volume, turn in opposite direction – to
decrease the volume.
21. STANDBY indicator – if the unit is turned off
using the remote control, the indicator lights
up (Standby mode), when you turn on the
unit, using the remote control, the indicator
goes down.
22. LED display – shows DVD playback info.
ENGLISH
5
3498.QXD 30.06.2005 23:39 Page 5
