![Asus b85m-k [8/48] B85m k specifications summary](/views2/1161718/page8/bg8.png)
viii
B85M-K specications summary
Specications are subject to change without notice.
BIOS features 64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI2.0, WfM 2.0, SM BIOS 2.7,
ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree
BIOS 3, My Favorites, Quick Note, Last Modied Log, F12 PrintScreen, F3
Shortcut functions and ASUS DRAM SPD (Serial Presence Detect) memory
information
Manageability WfM 2.0, DMI 2.0, WOL by PME, PXE
Support DVD Drivers
ASUS utilities
EZ Update
Anti-virus software (OEM version)
Operating System
Support
Windows
®
8.1
Windows
®
8
Windows
®
7
Form factor
uATX form factor: 8.9 in x 6.9 in (22.6 cm x 17.5 cm)
