ASUS H81M-R
1-13
6. Line In port (light blue). This port connects the tape, CD, DVD player, or other audio
sources.
7. Line Out port (lime). This port connects a headphone or a speaker. In 4-channel,
6-channel, and 8-channel congurations, the function of this port becomes Front
Speaker Out.
8. Microphone port (pink). This port connects a microphone.
Toconfigurean8-channelaudiooutput:
Use a chassis with HD audio module in the front panel to support an 8-channel audio
output.
9. USB 2.0 ports 3 and 4. These two 4-pin Universal Serial Bus (USB) ports are for USB
2.0/1.1 devices.
10. PS/2 keyboard port (purple). This port is for a PS/2 keyboard.
Audio 2.1, 4.1, 5.1 or 7.1-channel configuration
Port
Headset
2.1-channel
4.1-channel 5.1-channel 7.1-channel
Light Blue
(Rear panel)
Line In Rear Speaker Out Rear Speaker Out Rear Speaker Out
Lime (Rear panel) Line Out Front Speaker Out Front Speaker Out Front Speaker Out
Pink (Rear panel) Mic In Mic In Bass/Center Bass/Center
Lime (Front panel) — — — Side Speaker Out
For an 8-channel speaker setup, refer to the 7.1-channel conguration in the table.
