vi
B85M-GAMER specications summary
(continued on the next page)
Package contents
Check your motherboard package for the following items.
Motherboard
ASUS Gaming Motherboard – B85M-GAMER
Cables 2 x Serial ATA 6.0 Gb/s cables
Accessories 1 x I/O Shield
Application DVD Support DVD
Documentation User Guide
If any of the above items is damaged or missing, contact your retailer.
CPU
LGA1150 socket for Intel
®
4th and new 4th Generation Core™ i7 / i5 / i3,
Pentium
®
, and Celeron
®
processors
Supports Intel
®
22nm CPU
Supports Intel
®
Turbo Boost Technology 2.0*
* The Intel
®
Turbo Boost Technology 2.0 support depends on the type of CPU installed
in your system.
**
Refer to www.asus.com for Intel
®
CPU support list.
Chipset Intel
®
B85 Express Chipset
Memory
4 x DIMM, maximum 32 GB, DDR3 1600 / 1333 / 1066 MHz, non-ECC, un-buffered
memory*
Dual-channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)
* Hyper DIMM support is subject to the physical characteristics of individual CPUs.
Please refer to Memory QVL (Qualied Vendors List) for details.
**
Refer to www.asus.com for the latest Memory QVL (Qualied Vendors List).
***
Due to Intel
®
chipset limitation, DDR3 1600 MHz and higher memory modules on XMP
mode will run at the maximum transfer rate of DDR3 1600 MHz.
Graphics
Integrated graphics processor - Intel
®
HD Graphics support
- Supports HDMI with maximum resolution of 4096 x 2160 @24 Hz / 2560 x
1600 @60 Hz
- Supports D-Sub with maximum resolution of 1920 x 1200 @60 Hz
- Supports Intel
®
InTruTM 3D, Quick Sync Video, Intel
®
Clear Video HD
Technology, and Intel
®
Insider™
- Maximum shared memory of 1024 MB
Expansion
slots
1 x PCI Express 3.0/2.0 x16 slot (gray, at x16 mode)
2 x PCI Express 2.0 x1 slots
