viii
B85M-GAMER specications summary
Specications are subject to change without notice.
Rear Panel I/O
ports
1 x PS/2 keyboard port
1 x PS/2 mouse port
1 x HDMI port
1 x D-Sub port
1 x LAN (RJ45) port
2 x USB 3.0/2.0 ports
2 x USB 2.0/1.1 ports
8-channel audio I/O ports
Internal I/O
connectors
1 x 19-pin USB 3.0/2.0 connector supports additional 2 USB 3.0/2.0 ports
2 x USB 2.0/1.1 connectors support additional 4 USB 2.0/1.1 ports
1 x System panel
1 x Front panel audio connector (AAFP)
4 x SATA 6.0 Gb/s connectors (gray)
2 x SATA 3.0 Gb/s connectors (black)
1 x CPU Fan connector (4-pin)
1 x Chassis Fan connector (4-pin)
1 x COM connector
1 x 24-pin EATX Power connector
1 x 8-pin ATX 12V Power connector
1 x Clear CMOS jumper
BIOS features
64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.7, ACPI
4.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS 3, My
Favorites, Quick Note, Last Modied log, F12 PrintScreen Function, F3 Shortcut
function and ASUS DRAM SPD(Serial Presence Detect) memory information
Manageability Wfm 2.0, DMI 2.0, WOL by PME, PXE
Support DVD
Drivers
ASUS utilities
EZ Update
Anti-virus software (OEM version)
Form factor mATX form factor: 9.2 in. x 8.1 in. (23.3 cm x 20.6 cm)
