Chapter 1: Product introduction1-2
*ASUS System Web-based Management
If any of the above items is damaged or missing, contact your retailer.
1.1 System package contents
Check your system package for the following items.
1.2 Serial number label
Before requesting support from the ASUS Technical Support team, you must
take note of the product’s serial number containing 14 characters such as
xxS0xxxxxxxxxx shown as the gure below. With the correct serial number of the
product, ASUS Technical Support team members can then offer a quicker and
satisfying solution to your problems.
Model Name RS100-E7/PI2
Chassis ASUS R09 1U Rackmount Chassis
Motherboard ASUS P8B-M Server Board
Component 1 x 220W Single Power Supply
2 x SATA Cables
1 x PCI Express x16 Riser Card (PCIE16-R11)
1 x Front I/O Board (FPB-R9)
1 x USB Board (USB-R9)
2 x System Fans (40mm x 28mm)
Accessories 1 x RS100-E7/PI2 User’s Guide
1 x RS100-E7/PI2 Support CD
1 x Bag of Screws
1 x AC Power Cable
Optional
Items
CPU Heatsink
ASUS ASMB5-iKVM Remote management card
Slim-type Optical Device
Ball Bearing Rail Kit
xxS0xxxxxxxxxx
RS100-E7/PI2
