Asus rs100-e7-pi2 [16/130] Internal features

Chapter 1: Product introduction1-6

1.6 Internal features

The barebone server includes the basic components as shown.

The barebone server does not include a oppy disk drive. Connect a USB oppy

disk drive to any of the USB ports on the front or rear panel if you need to use a

oppy disk.

Turn off the system power and detach the power supply before removing or

replacing any system component.

*WARNING

HAZARDOUS MOVING PARTS

KEEP FINGERS AND OTHER BODY PARTS AWAY

1. PCI Express x16 Riser Card (at x16 link)

2. System Fan (x2) (9GV0412P3J051)

3. ASUS P8B-M Server Board

4. Power Supply

5. HDD Tray 2 (hidden) and Slim-type Optical

Drive (optional)

6. HDD Tray 1
