Asus z170-a [15/130] Layout contents

ASUS Z170-A Series

1-3

1.2.4 Layout contents

Connectors/Jumpers/Slots/LED Page

1. ATX power connectors (24-pin EATXPWR, 8-pin EATX12V)

1-26

2. Intel

LGA1151 CPU socket 1-4

3. CPU, water pump, CPU optional, extension, and chassis fan connectors

(4-pin CPU_FAN; 3-pin W_PUMP; 4-pin CPU_OPT; 5-pin EXT_FAN; 4-pin

CHA_FAN1-4)

1-25

4. DDR4 DIMM slots 1-8

5. MemOK! button 1-36

6. USB 3.0 connectors (20-1 pin USB3_12, USB3_34)

1-31

7. Intel

Z170 Serial ATA 6.0 Gb/s connectors (7-pin SATA6G_12,

SATA6G_34, SATA6G_56, SATA Express)

1-24

8. M.2 Socket 3 1-28

9. TPU switch 1-37

10. Clear RTC RAM (2-pin CLRTC) 1-19

11. System panel connector (20-3 pin PANEL) 1-30

12. DirectKey connector (2-pin DRCT) 1-28

13. EZ XMP switch 1-38

14. USB 2.0 connectors (10-1 pin USB1112, USB1314) 1-29

15. Thunderbolt header (5-pin TB_HEADER) 1-32

16. TPM connector (14-1 pin TPM) 1-29

17. Power-on button 1-38

18. Serial port connector (10-1 pin COM) 1-23

19. Front panel audio connector (10-1 pin AAFP) 1-27

20. Digital audio connector (4-1 pin SPDIF_OUT) 1-27

21. Flashback header (12-1 pin FLBK_HEADER) 1-33

22. T_Sensor connector (2-pin T_SENSOR) 1-32

23. CPU Over Voltage jumper (3-pin CPU_OV) 1-20
