Asus z170-a [19/130] Cpu heatsink and fan assembly installation
![Asus z170-a [19/130] Cpu heatsink and fan assembly installation](/views2/1162356/page19/bg13.png)
ASUS Z170-A Series
1-7
1.3.2 CPU heatsink and fan assembly installation
Apply the Thermal Interface Material
to the CPU heatsink and CPU
before you install the heatsink and
fan, if necessary.
To install the CPU heatsink and fan assembly
