Asus z170-a [22/130] Ddr4 3200 o c mhz capability
![Asus z170-a [22/130] Ddr4 3200 o c mhz capability](/views2/1162356/page22/bg16.png)
1-10
Chapter 1: Product Introduction
DDR4 3333 (O.C.) MHz capability
DDR4 3300 (O.C.) MHz capability
Vendors Part No. Size SS/
DS
Chip
Brand
Chip NO. Timing Voltage DIMM socket
support (Optional)
1 2 4
G.SKILL F4-3333C16D-8GTZ 8GB(4GB*2) SS SK Hynix H5AN4G8NMFR 16-18-18-38 1.35V •
G.SKILL F4-3333C16Q-16GRKD 16GB(4GB*4) SS Samsung K4A4G085WD 16-16-16-36 1.35V •
CORSAIR CMD16GX4M4B3333C16
ver4.23
16GB(4GB*4) SS Samsung K4A4G085WD 16-18-18-36 1.35V •
A-DATA AX4U3333W4G16 16GB(4GB*4) SS SK Hynix H5AN4G8NMFR 16-16-16-36 1.35V •
Vendors Part No. Size SS/
DS
Chip
Brand
Chip NO. Timing Voltage DIMM socket
support (Optional)
1 2 4
G.SKILL F4-3300C16Q-16GRK 16GB(4GB*4) SS SK Hynix H5AN4G8NMFR 16-16-16-36 1.35V • •
G.SKILL F4-3300C16D-8GTZ 8GB(4GB*2) SS Samsung K4A4G085WD 16-18-18-38 1.35V • •
CORSAIR CMD16GX4M4B3300C16 16GB(4GB*4) SS Samsung K4A4G085WD 16-18-18-36 1.35V •
DDR4 3200 (O.C.) MHz capability
Vendors Part No. Size SS/
DS
Chip
Brand
Chip NO. Timing Voltage DIMM socket
support (Optional)
1 2 4
G.SKILL F4-3200C16Q-16GRR 16GB(4GB*4) SS SK
Hynix
H5AN4G8NMFR 16-16-16-36 1.35V • •
G.SKILL F4-3200C16Q-16GRB 16GB(4GB*4) SS SK
Hynix
H5AN4G8NMFR 16-16-16-36 1.35V • •
G.SKILL F4-3200C16Q-16GRRK 16GB(4GB*4) SS SK
Hynix
H5AN4G8NMFR 16-16-16-36 1.35V • •
AVEXIR AVD4U32001604G-4BZ1 16GB(4GB*4) SS SK
Hynix
H5AN4G8NMFR 16-18-18-36 1.35V •
AVEXIR AVD4U32001604G-4CIR 16GB(4GB*4) SS 16-18-18-36 1.35V •
CORSAIR CMD16GX4M4A3200C16 16GB(4GB*4) SS 16-18-18-36 1.35V •
GEIL GPR416GB3200C15QC 16GB(4GB*4) SS 15-15-15-35 1.35V •
Kingston HX432C16PB2K4/16 16GB(4GB*4) SS 16-16-16-39 1.35V •
Panram PUD43200C164G4NJW 16GB(4GB*4) SS 16-18-18-39 1.35V •
Vendors Part No. Size SS/DS Chip
Brand
Chip NO. Timing Voltage DIMM socket
support (Optional)
1 2 4
CORSAIR CMD16GX4M4B3400C16
ver. 4.23
16GB(4GB*4) SS Samsung K4A4G085WD 16-18-18-38 1.35V •
DDR4 3400 (O.C.) MHz capability
Z170-AMotherboardQualiedVendorsLists(QVL)
