Asus z170-a [9/130] Z170 a specifications summary
![Asus z170-a [9/130] Z170 a specifications summary](/views2/1162356/page9/bg9.png)
ix
Z170-A specications summary
USB
Intel
®
Z170 Express Chipset- supports ASUS USB 3.1 Boost
- 6 x USB 3.0/2.0 ports (4 ports at mid-board, 2 ports at back panel, blue)
- 6 x USB 2.0/1.1 ports (4 ports at mid-board, 2 ports at back panel)
ASMedia
®
USB 3.1 controllers- supports ASUS USB 3.1 Boost and 3A
power output
- 1 x USB 3.1/3.0/2.0 ports at back panel (teal blue, Type-A)
- 1 x USB 3.1/3.0/2.0 port at back panel (Type-C)
ASUS
Exclusive
Features
Superb Performance
OC Design - ASUS PRO Clock Technology
- Full BCLK range for extreme overclocking performance
5-Way Optimization
- Whole system optimization with a single click! Perfectly consolidates better
CPU performance, power saving, digital power control, system cooling and
app usages.
DIGI+ VRM
-CPU Power: Digital 8-phase power design
-iGPU Power: Digital 2-phase power design
TPU
- Auto Tuning, TPU, GPU Boost, 2-level TPU switch
EPU
- EPU
Fan Xpert 3 featuring Fan Auto Tuning function and multiple thermistors
selection for optimized system cooling control
Turbo App featuring system performance tuning, network priority, and audio
scene conguration for selected applications.
UEFI BIOS
- Most advanced options with fast response time
Special Memory O.C. Design
- Superb memory O.C. capability under full load by minimizing the coupling
noise and signal reection effect
PC Cleaner
- Fast and easy way to get rid of unnecessary junk les
Remote Entertainment
Remote GO!
- Remote GO! Function: Cloud GO!, Remote Desktop, Remote Keyboard &
Mouse, File Transfer
- Wi-Fi GO! & NFC Remote app for portable smartphone/tablet, supporting iOS 7
& Android 4.0 systems
Media Streamer
- Pipe music or movies from your PC to a smart TV, your entertainment goes
wherever you go!
- Media Streamer app for portable smartphone/tablet, supporting iOS 7 &
Android 4.0 systems
HyStream
- Stream iOS devices’ screen on your PC screen.*
* Contact your device vendor for supporting information.
(continued on the next page)
