Asus b150 pro gaming d3 [6/94] Package contents
![Asus b150 pro gaming d3 [6/94] Package contents](/views2/1162406/page6/bg6.png)
vi
B150 PRO GAMING D3 specications summary
(continued on the next page)
Package contents
Check your motherboard package for the following items.
Motherboard
ASUS Gaming Motherboard – B150 PRO GAMING D3
Cables
4 x Serial ATA 6.0 Gb/s cables
Accessories
1 x I/O Shield
1 x PRO GAMING cable labels
1 x M.2 screw package
Application DVD Support DVD
Documentation User Guide
If any of the above items is damaged or missing, contact your retailer.
CPU
LGA1151 socket for 6th Generation Intel
®
Core™ i7 / i5 / i3, Pentium
®
, and
Celeron
®
processors
Supports Intel
®
14nm CPU
Supports Intel
®
Turbo Boost Technology 2.0*
* The Intel
®
Turbo Boost Technology 2.0 support depends on the CPU types.
** Refer to www.asus.com for Intel
®
CPU support list.
Chipset
Intel
®
B150 Express Chipset
Memory
4 x DIMMs, maximum 64 GB, DDR3 1866(O.C.)/1600/1333 MHz, non-ECC, un-
buffered memory*
Dual-channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)
* Hyper DIMM support is subject to the physical characteristics of individual CPUs. Please
refer to Memory QVL (Qualied Vendors List) for details.
** Refer to www.asus.com or this user manual for the Memory QVL (Qualied Vendors
List).
*** Due to Intel
®
chipset limitation, DDR3 1866 MHz and higher memory modules on XMP
mode will run at the maximum transfer rate of DDR3 1866 MHz.
****To ensure system stability, either install DDR3L DIMMs or DDR3 DIMMs with voltage
lower than 1.5V.
Graphics
Integrated graphics processor - Intel
®
HD Graphics support
Multi-VGA output support: HDMI, D-Sub ports
- Supports HDMI 1.4b with maximum resolution of 4096 x 2160 @24Hz
- Supports RGB with maximum resolution of 1920 x 1200 @60Hz
Supports Intel
®
InTru
TM
3D, Quick Sync Video, Intel
®
Clear Video HD Technology,
and Intel
®
Insider
TM
Maximum shared memory of 512 MB
Expansion
slots
1 x PCI Express 3.0 x16 slot (gray, at x16 mode)
1 x PCI Express 3.0 x16 slot (black, max. at x4 mode, compatible with PCIe x1 and
x4 devices)
2 x PCI Express 3.0 x1 slots*
2 x PCI slots
* When PCIE x16_2 is occupied by x4 or faster devices, PCIE x1_1 and PCIE x1_2 will be
disabled.
