Asus b150 pro gaming d3 [68/94] Usb configuration
![Asus b150 pro gaming d3 [68/94] Usb configuration](/views2/1162406/page68/bg44.png)
SATA Controller(s) [Enabled]
Enables or disables onboard the SATA device. Conguration options: [Disabled] [Enabled]
The following items appear only when you set the SATA Controller(s) to [Enabled].
SATA Mode Selection [AHCI]
Allows you to set the SATA conguration.
[AHCI] Set to [AHCI] when you want the SATA hard disk drives to use the AHCI
(Advanced Host Controller Interface). The AHCI allows the onboard storage
driver to enable advanced Serial ATA features that increases storage
performance on random workloads by allowing the drive to internally
optimize the order of commands.
Aggressive LPM Support [Disabled]
This item is designed for LPM (link power management) support with a better energy saving
conditions. When disabled, the hot plug function of SATA ports are disabled. Conguration
options: [Disabled] [Enabled]
SMART Self Test [On]
S.M.A.R.T. (Self‑Monitoring, Analysis and Reporting Technology) is a monitoring system that
shows a warning message during POST (Power‑on Self Test) when an error occurs in the
hard disks. Conguration options: [On] [Off]
SATA6G_1~6(Gray) [Enabled]
Allow you to enable/disable the SATA6G_1~6 port. Conguration options: [Disabled]
[Enabled]
Hot Plug [Disabled]
These items allow you to enable/disable SATA Hot Plug Support. Conguration options:
[Disabled] [Enabled]
2.6.6 USB Conguration
The items in this menu allow you to change the USB‑related features.
The USB Devices item shows the auto‑detected values. If no USB device is detected, the
item shows None.
Legacy USB Support [Enabled]
[Enabled] Your system supports the USB devices in legacy operating systems.
[Disabled] Your USB devices can be used for BIOS setup only and cannot be
recognized in the boot devices list.
[Auto] Your system automatically detects the presence of USB devices at startup.
If any USB devices are detected, the legacy USB support is enabled.
XHCI Hand-off [Disabled]
[Enabled] Enables the support for operating systems without an XHCI hand‑off
feature.
[Disabled] Disables the XHCI Hand‑off support.
2‑28 Chapter 2: Getting started
