ASUS N3150I-C / N3050I-C
1-9
N3050I-C
N3150I-C / N3050I-C Display panel
backlight power selection
1 2
2 3
12V
(Default)
5V
BLKT_PWR_SEL
N3150I-C
3. Chassis intrusion connector (4-1 pin CHASSIS)
This connector is for a chassis-mounted intrusion detection sensor or switch.
Connectoneendofthechassisintrusionsensororswitchcabletothis
connector.Thechassisintrusionsensororswitchsendsahigh-levelsignalto
thisconnectorwhenachassiscomponentisremovedorreplaced.Thesignal
isthengeneratedasachassisintrusionevent.
Bydefault,thepinslabeled“Intruder”areshortedwithajumpercap.Remove
the jumper caps only when you intend to use the chassis intrusion detection
feature.
Pins Setting
1-2(Default) 12V
2-3 5V
4. Display panel backlight power selector (3-pin BLKT_PWR_SEL)
N3050I-C
PIN 1
+5VSB_MB
Chassis Signal
GND
CHASSIS
N3150I-C / N3050I-C Chassis intrusion connector
N3150I-C
